Wheeled Digger 6ton Wheel Excavator R60wvs

Wheeled Digger 6ton Wheel Excavator R60wvs image

Get a Quote Email to us

Product Description

Basic Info.

Model NO.

R60WVS

Drive Type

Internal Combustion Drive

Bucket Capacity

0.21cbm

Size

Small-Scale

Certification

CE, ISO9001: 2000

Condition

New

Opearating Weight

5750kg

Engine Model

4tnv98-E

Rated Power

42.5/2400kw/Rpm

Ground Pressure

22kpa

Displacement

3.319L

Max. Torque

20.6/1800kgf.M/Rpm

Fuel Tank

125L

Gradeability

70%

Max. Digging Range

6150mm

Max. Digging Height

6070mm

Max. Dumping Height

3500mm

Min. Turning Radius

2350mm

Transport Package

Nude Package

Specification

6100*1925*2850mm

Trademark

CRUKING

Origin

China

HS Code

8429521200

Production Capacity

500sets/Year

Product Description

6ton Wheel Excavator R60WVS

Product Features
The new Tier3 engine has lower fuel costs; diesel fuel is fully and thoroughly combusted, which greatly improves performance; multiple fuel filtration systems ensure that the engine is durable to use while reducing harmful gas emissions and more environmentally friendly.
-Install small arms flow assembly system and large arm holding system;
-Parking brake to ensure smoother and easier control during rotation;
-The hydraulic shock valve on the walking foot pedal and the lubricating rotary reducer are installed without oil leakage chamber;
-Longer service life of hydraulic oil and filter element;

Engine power: 40.5 kw / 2,400 rpm
Engine: 4TNV98-E
Operating weight: 5,520kg
Walking speed: 30km/h
Maximum digging height: 6,070mm
Maximum digging depth: 3,500mm
Total length: 6100mm
Total height: 2850mm
Main Parameters

Overall weight	kg	5520
Bucket capacity	M3	0.21
Model	—	4TNV98-E
Rated power	Kw/rpm	40.5/2400
Max. torque	kgf.m/rpm	20.6/1800
Working pressure	Kg/cm2	240
Rated flow	L/min	138
Max. traction force	kgf
Walking speed	Km/h	30
Gradeability	°	35
Overall length	mm	6100
Overall width	mm	1925
Overall height	mm	2850
Rear turning radius	mm	1650
Fuel tank	L	125
Hydraulic oil tank	L	70
Max. digging radius	mm	6150
Ground Max. digging radius	mm	5980
Max. digging depth	mm	3500
Max. vertical digging depth	mm	2960
Max. digging height	mm	6070
Max. dumping height	mm	4340
Min. Turning radius	mm	2350
