Straight Boom Truck Mounted Crane Sq12sk3q
Straight Boom Truck Mounted Crane Sq12sk3q image
Basic Info.
Model NO.
SQ12SK3Q
Shaft Number
3
Crane Jib
Four-Arm
Type
Straight Arm
Transport Package
by Container or Roro
Specification
12Ton
Trademark
China brand
Origin
China Xuzhou
Production Capacity
1000units/Year
Product Description
Straight Boom Truck Mounted Crane SQ12SK3Q
1,Throttle Control System
Changing the form of previous manipulation and throttle operation individually,Realization of the bilateral handle synchronous and driving throttle acceleration and deceleration automatically, due to the speed change steady,it can easily to carry out the lifting work.
2,End position automatic hook device
Maximum savings in preparation time before and after operation, to ensure that customer’s vehicle could be in a driving state in the shortest time, and prevent crane damage accident caused by hoist swing to enhance the safety of driving.
3,Hoisting overwinder device
If a user is negligent or unfamiliar with the operation of lifting hooks,the hoisting overwinder device will stop hook raise in
time, to prevent the safety of personal and property caused by fracture of wire rope.
4,Slewing locking device
Slewing locking device can ensure that the lifting arm does not sway because of the centrifugal force during the driving and steering process of the vehicle,to avoid all kinds of accidents caused by swaying.
5,Dual pump converging
The hydraulic system adopts dual high pressure gear pump, multi-way valve hoisting joint to realize the converging, to improve the speed of winch, at the same time, it can realize the compound action of crane.
6,Torque limiter
It can select torque limit overload protection device to prevent users because of negligence or unfamiliar with the lifting
operation principle of overload operation, thereby causing the vehicle rollover and crane damage accidents.
1,Throttle Control System
Changing the form of previous manipulation and throttle operation individually,Realization of the bilateral handle synchronous and driving throttle acceleration and deceleration automatically, due to the speed change steady,it can easily to carry out the lifting work.
2,End position automatic hook device
Maximum savings in preparation time before and after operation, to ensure that customer’s vehicle could be in a driving state in the shortest time, and prevent crane damage accident caused by hoist swing to enhance the safety of driving.
3,Hoisting overwinder device
If a user is negligent or unfamiliar with the operation of lifting hooks,the hoisting overwinder device will stop hook raise in
time, to prevent the safety of personal and property caused by fracture of wire rope.
4,Slewing locking device
Slewing locking device can ensure that the lifting arm does not sway because of the centrifugal force during the driving and steering process of the vehicle,to avoid all kinds of accidents caused by swaying.
5,Dual pump converging
The hydraulic system adopts dual high pressure gear pump, multi-way valve hoisting joint to realize the converging, to improve the speed of winch, at the same time, it can realize the compound action of crane.
6,Torque limiter
It can select torque limit overload protection device to prevent users because of negligence or unfamiliar with the lifting
operation principle of overload operation, thereby causing the vehicle rollover and crane damage accidents.
|
Truck with
loading crane |
ITEM
|
UNITS
|
SQ12SK3Q
|
|
Max lifting capacity
|
KG
|
12000
|
|
|
Max lifting capacity
|
T.M
|
30
|
|
|
Recommend power
|
KW
|
30
|
|
|
Max oil flow
|
L/MIN
|
63
|
|
|
Max pressure
|
MPA
|
26
|
|
|
Oil Tank Capacity
|
L
|
160
|
|
|
Crane weight
|
KG
|
4200
|
|
|
Installation space
|
MM
|
1300
|
|
|
Rotation angle
|
DEGREE
|
360 All Rotation
|
|
|
Max extension length
|
MM
|
12500
|
|
|
Max lifting height
|
MM
|
13500
|
|
|
Max elevation
|
DEGREE
|
75
|
We are China Straight Boom Truck Mounted Crane Sq12sk3q manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
