Sem 170HP Reinforced Motor Grader 917 with Cummins Engine

Sem 170HP Reinforced Motor Grader 917 with Cummins Engine image

Get a Quote Email to us

Product Description

Basic Info.

Model NO.

917

Walking Mode

Wheeled

Type

Small Grader

Operation Weight (Base Machine)

15,070kg

Max. Lifting Height

475mm

Max. Depth of Cut

715mm

Max. Drawbar

≥78kn

Wheelbase

6,140mm

Transport Package

RO-RO/Bulk/Container

Specification

8854*2630*3360mm

Trademark

SEM

Origin

China

HS Code

84292090

Production Capacity

1000 Set Per Month

Product Description

SEM 170Hp Reinforced Motor Grader 917 with Cummins Engine

Parameter

Items	SEM919
Operation Weight (Base Machine)	15,070kg
Overall Dimensions (LWH)	8,7032,6303,360mm
Blade Length (LWH)	3,97425607mm
Max. Lifting Height	475mm
Max. Depth of Cut	715mm
Max. Drawbar	≥78kN
Wheelbase	6,140mm
Frame Articulation Angle	20°
Min. Turning Radius	7.8m
Engine Brand	SDEC SC9DK190.1G3
Rated power	140kW
Transmission Type	Hangchi 6WG180
Travel Speed (Forward/Rear)	40/25km/h
Rear Axle/Tandem	SEM ST22
Service brake	Outboard disc with brake caliper,Air to oil Control
Oscillation (Front up/Rear up)	15/25°
Max. Oscillation Angle	±16°
Steering Angle (Left/Right)	47.5°
Max. Lean Angle of Front Wheels	18°
Hydraulic System	Load sensing,PPPC

Product Show
