Roller Machine Pneumatic Tyre Roller XP163

Roller Machine Pneumatic Tyre Roller XP163 image

Get a Quote Email to us

Product Description

Basic Info.

Model NO.

XP163

Compaction Depth

2055mm

Engine Type

Diesel Engine

Travel Speed

0-18.4km/H

Centrifugal Force

Certification

EPA, CE, ISO 9001:2000, ISO 9001:2008

Condition

New

Operating Weight

16000kg

Rolling Pressure

200-400kpa

Min. Turning Radius

7230mm

Compacting Width

2055mm

Overlapping of Front&Rear Tyre

30mm

Exciting Force

320/235kn

Tyre Numbers

Front4 Rear5

Engine Power

92kw/2200rpm

Min.Ground Clearance

250mm

Engine Model

Yc4a125z

Transport Package

Nude Package

Specification

4780*2210*3395mm

Trademark

CRUKING

Origin

China

HS Code

8429401900

Production Capacity

500sets/Year

Product Description

Roller Machine 16ton Tyre Roller XP163

Product Features

XP163 tyre roller is a large-tonnage tyre roller produced according to market requirements, which will take pneumatic tyres as a working device for compacting paved materials. The tyre roller is mainly applicable for compacting operation of asphalt pavement, foundation layer, secondary foundation layer, dam and filling engineering. It is an ideal set of compacting equipment for building high-grade highways, airports, ports, dams and industrial construction sites.

Parameters

Item	Unit	XP103	XP163	XP163S	XP203
Maximum operating weight	kg	10000	16000	16000	20000
Water tank capacity	L	650 L	650 L	650 L	650 L
Counterweight total	kg	650	3600	3600	7600
Engine Model	–	SC4H125.2G3	SC4H115.4G2B	SC4H115.4G2B	SC4H115.4G2B
Rated Power	kW/rpm	92 /1800	86 /1800	86 /1800	86 /1800
Speed range(forward)
Speed(1)	km/h	0-4	0-4	0-6.9	0-4
Speed(2)	km/h	0-8.7	0-8.3	0-12.7	0-8.3
Speed(3)	km/h	0-18.4	0-17.5	–	0-17.5
Speed range(backward)
Speed(1)	km/h	0-4	0-4	–	0-4
Speed(2)	km/h	0-8.7	0-8.3	–	0-8.3
Max. gradeability	%	30	20	33	20
Track radius, out	mm	7253	7330	7330	7330
Ground clearance	mm	300	260	260	260
Wheelbase	mm	3700	3700	3700	3700
Steering angle	°	±35°	±35°	±35°	±35°
Braking distance	m	5.9	5.2	5.2	5.2
Working width	mm	2055	2055	2055	2055
Tire numbers	–	Front 4/Rear 5	Front 4/Rear 5	Front 4/Rear 5	Front 4/Rear 5
Tire overlap	mm	30	45	45	45
Ground pressure	kPa	150~ 300	150~ 300	150~ 300	200~ 400
Tyre size	–	9.00-20-12PR	11.00-20-16PR	11.00-20-16PR	11.00-20-16PR
Number of tire layers	–	12	16	16	16
Tyre pressure	kPa	600~ 650	600~ 650	600~ 650	600~ 650
Overall dimensions	mm	4780×2098×3340	4800×2356×3330	4800×2356×3330	4800×2356×3330

Detailed Photos
