Professional Design Haitui 220HP HD22 Crawler Bulldozer Sale in Algeria

China
                Professional Design Haitui 220HP HD22 Crawler Bulldozer Sale in Algeria
             supplier

Professional Design Haitui 220HP HD22 Crawler Bulldozer Sale in Algeria image

Get a Quote Email to us

  • Overview
  • Product Description
  • Product Parameters
  • Packaging & Shipping
  • Company Profile

Overview

Basic Info.

Model NO.
HD22

Engine Power
175 Kw

Certification
CE

Condition
New

Color
Yellow

Operating Weight
23500 Kg

Engine Model
Nt855-C280s10

Transport Package
Roro/Bulk

Specification
5460*3725*3395 mm

Trademark
Haitui

Origin
China

HS Code
8429119000

Production Capacity
100units/Month

Product Description

Professional Design Haitui 220hp HD22 Crawler Bulldozer Sale in Algeria



Product Description



HD22 crawler bulldozer is a 220 horsepower track-type dozer with power shift transmission. It equipped with famous Cummins NT855-C280S10 engine gives you more power and reliability you need. The highly reliable power shift transmission, stable torque converter and the two-stage straight-tooth structure final drive transmit power efficiently. It can be equipped with a variety of working devices and cabs to meet the various working conditions. They are ideal and efficient equipment for earth and stone construction work and bulk scraping.


•Famous CUMMINS NT855-C280S10 engine gives you more power and reliability you need. Improved fuel economy over the previous model with strong torque output and low fuel consumption gives you excellent overall fluid efficiency.

•The highly reliable power shift transmission, stable torque converter and the two-stage straight-tooth structure final drive transmit power efficiently.

•It can realize automatic fault diagnosis and full monitoring. The overall cast instrument panel integrates air conditioning, electrical appliances and instruments into one, which is more beautiful and luxury.

•According to the ergonomic design, the driver’s seat and armrest can be adjusted up and down, the shifting, steering and throttle are placed on the left side, and the soft shaft structure is adopted. The working device is operated on the right side, and the servo control system is used to make the operation process more light and flexible.

•The standard straight tilt blade features powerful cutting force and the three-shank ripper can be equipped for the ripping of clay and frozen earth.



Product Parameters
Overall Dimension 5460×3725×3395 mm
Operating Weight 23500 kg
ENGINE Model Cummins NT855-C280S10
Type Water-cooled, In-line, overhead valve direct injection, turbocharged diesel
Number of Cylinders 6
Bore × Stroke Φ139.7×152.4 mm
Piston Displacement 14.01 L
Rated Power 175 KW (238HP) @1800 rpm
Max Torque 1030 N·m @1300 rpm
Fuel Consumption 205 g/kW·h
TRANSMISSION Torque Converter 3-element, 1 stage, 1 phase
Transmission Planetary gear type, power-shift, forced lubrication
Central Drive Shaft Spiral bevel gear, single-stage speed reduction, splash lubrication
Steering clutch Wet, multi-disc, spring loaded, hydraulically separated, hydraulic control
Steering brake Wet type,floating band structure,foot brake with hydraulic booster
Final drive 2-stage speed reduction of spur gear, splash lubrication
TRAVEL SPEED Gear 1st 2nd 3rd
Forward 0~3.6 km/h 0~6.5 km/h 0~11.2 km/h
Reverse 0~4.3 km/h 0~7.7 km/h 0~13.2 km/h

UNDERCARRIAGE SYSTEM
Type Sprayed beam, suspended structure of equalizer
No. of Carrier Rollers 2 each side
No. of Track Rollers 6 each side
No. of Track Shoes 38 each side
Track Shoe type Single Grouser
Width of Track shoe 560 mm
Pitch 216 mm
Track Gauge 2000 mm
Ground Pressure 0.077 Mpa
HYDRAULIC SYSTEM Max Pressure 14 Mpa
Pump Type Gear Pump
Displacement 262 L/Min
Bore of Working Cylinder 120 mm × 2

BLADE
Blade Type Straight-tilt Blade Angle Blade Semi-U-blade
Blade Capacity 6.4 m³ 4.7 m³ 7.5 m³
Blade Width 3725mm 4365 mm 3725 mm
Blade Height 1315 mm 1055 mm 1374 mm
Max Drop Below Ground 538 mm 535 mm 540 mm
MaxTilt Adjustment >735 mm >500 mm >755 mm
THREE SHANK RIPPER Max digging depth  666 mm
Max lift above ground 555 mm
Weight of 3-shank ripper 2495 kg
SINGLE SHANK RIPPER Max digging depth  695 mm
Max lift above ground 515 mm
Weight of 1-shank ripper 2453 kg
Packaging & Shipping

Company Profile



We are China Professional Design Haitui 220HP HD22 Crawler Bulldozer Sale in Algeria manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
