HOWO LHD/Rhd 336HP 16m3 Garbage Compactor Truck
HOWO LHD/Rhd 336HP 16m3 Garbage Compactor Truck image
Basic Info.
Product Description
HOWO LHD/RHD 336HP 16m3 Garbage Compactor Truck
Our company will offer you the high quality proudcts with a low price, Quick delivery,and professional after-sale service.
Product Describution:
The compression garbage truck controlled by the integration of the machinery, electricity and hydraulic ,
with manual control system. Crush the garbage through fling, pushing and spading, finally make the waste compaction in the dustbin.
Features:
1.Howo chassis, perfect perfomance.
2.Weichai engine, super powerful; reliable performance.
3.Nice shape, rational structure
4.High quality hydraulic system
5.Massive, durable, perfect performance
6.Prolonged service life
Grabage Truck Specification :
| Production name | HOWO compactor garbage truck 16cbm |
| Chassis model | ZZ1257 |
| Type | 6×4, Right/Left hand drive |
| Weights | |
| Related weight (kg) | 30000 |
| Curb weight (kg) | 14000 |
| Dimensions | |
| Wheelbase(mm) | 4600+1350 |
| Overall Dimension(mm) | 10100×2500×3400 |
| Box dimension (mm) | 16m3 |
| Max speed(km/h) | 90 |
| Engine | |
| Engine model | WD615 (336HP) |
| Engine type | 4 stroke water-cooled, inter-cooling |
| No of cylinder | straight-6 cylinders |
| Displacement(L) | 9.726L |
| Max power(kw) | 249kw |
| Drive Line | |
| Transmission | HW13710CL |
| 10 speeds,10 forwards,2 reverse gear,manual operation | |
| Steering | ZF8098 Power steering |
| Cab | |
| Cabin | HW76 cab |
| Configuration standard | Air conditioner ,and so on |
| Axles | |
| Front axles | HF7 |
| Rear axles | MCY13 |
| Tire specification | |
| Tire | 12.00-20 standard tire,10 tires+1 spare tire |
| Specification of compactor garbage truck | |
| Box valume | 16m3 |
| Box material | Side 4mm,bottom 5mm |
| Sewage tanker | 200L |
| Fill volume | 1.2cbm |
| Loading time | 20-30S |
| The cycle time of the loading | 50-60S/per turn |
| Unloading model | Dump |
| Unloading time | 40-50S |
| Hydraulic system pressure | 16Mpa |
We are China HOWO LHD/Rhd 336HP 16m3 Garbage Compactor Truck manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
