High Quality Torque Rotary Drilling Rig Earth Drill Machine Xr150d
High Quality Torque Rotary Drilling Rig Earth Drill Machine Xr150d image
Basic Info.
Model NO.
Xr150d
Bit Type
Diamond Bit
Drilling Way
Compound
Type
Crawler
Transport Package
Cartons
Trademark
top brand
Origin
China
HS Code
8429521200
Production Capacity
500000
Product Description
High Quality Torque Rotary Drilling Rig Earth Drill Machine Xr150d
150KN.M Rotary Drilling Rig XR150D For sale
Our company will offer you the best quality products with reasonable
price,quick delivery,and professional after-sale service.
Please don’t hesitate to let us know if you have any questions about
the products.Your reply would be highly appreciated.
| Name | Unit | Parameters | ||
|---|---|---|---|---|
| 1 | Max. drilling diameter | mm | 1300 | |
| 2 | Max. drilling depth | m | 38(4-section of friction) (standard) 48(5-section of friction) (optional) 38(4-section of mechanical interlock ) (optional) |
|
| 3 | Safe operation range(from rotarying centre) | mm | 3150~3550 | |
| 4 | Dimension in working condition(L×W×H) | mm | 7122×4200×17250 | |
| 5 | Dimension in transportation condition(L×W×H) | mm | 12300×3200×3060 | |
| 6 | Overall drilling weight(drilling tools not included) | t | 45.5 | |
| 7 | Engine | Engine model | B5.9-C | |
| Engine rated power/rotary speed | kW | 133 /2000r/min | ||
| Max. Torque of engine | N.m | 553 /1500r/min | ||
| 8 | Hydrulic system | Max. pressure | Mpa | 32 |
| 9 | Rotary drive | Max.output torque | kN.m | 150 |
| Rotary speedRotary speed | rpm | 6~28 | ||
| 10 | Pull-Down clinder | Max. pull-down piston push | kN | 120 |
| Max. pull-down piston pull | kN | 160 | ||
| Max. pull-down piston stroke | mm | 3500 | ||
| 11 | Main winch | Max. pulling force | kN | 145 |
| Max. wire speed | m/min | 75 | ||
| Wire diameter | mm | 26 | ||
| 12 | Auxiliary winch | Max. pulling force | kN | 50 |
| Max. wire speed | m/min | 70 | ||
| Wire diameter | mm | 16 | ||
| 13 | Mast | Left/ right Side | ° | 3/3 |
| Forwards | ° | 5 | ||
| 14 | Slewing bearing | Slewing bearing angle | ° | 360 |
| 15 | Runing | Max. complete device running speed | km/h | 3.2 |
| Max. complete device grade ability | % | 40 | ||
| 16 | Track | Track width | mm | 800 |
| Outside width(min-max) | mm | 3200~4200 | ||
| Distance between two wheels longitudinally | mm | 3843 | ||
| Average grouning specific pressure | KPa | 70.5 | ||
We are China High Quality Torque Rotary Drilling Rig Earth Drill Machine Xr150d manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
Tags: Earth Drill Machine, High Quality Torque Rotary Drilling Rig Earth Drill Machine Xr150d, Rotary Drilling RigSimilar Or Related
