High Quality Oriemac Mini Crawler Excavator Xe60ca Xe60d

High Quality Oriemac Mini Crawler Excavator Xe60ca Xe60d image

Get a Quote Email to us

Product Description

Basic Info.

Model NO.

XE60CA

Size

Large-Scale

Certification

CE, ISO9001: 2000

Condition

New

Color

Yellow

Model

Xe60

Engine

39.8kw

Max. Bucket Capacity

0.23m3

Transport Package

Nude, Suitable for Shiping

Specification

ISO

Trademark

Oriemac

Origin

Jiangsu, China

Production Capacity

100 Sets/Month

Product Description

Small excavator XE60CA

1. Operation weight: 5630kg
2. Standard 0.23m3 bucket
3. Max. Digging height: 5630mm
4. US OILGEAR hydraulic system
5. Engine: 39.8kw JAPAN YANMAR 4TNV94L
6. Electronic system
7. Cabin with A/C, ROPS/FOPS
8. With break hammer SB40/GB2T
9. With Rubber crawler

Hydraulic crawler excavator XE60 produced in CAT technology with Japan YANMAR engine has very good performance, it can be equipped with RUBBER CRAWLER, specially suitable for city road use, it could be used for digging dutches, and break normal concrete road.

US OILGEAR hydraulic system and electronic system has provided XE40 excavator with reliable and excellent performance.

XE60CA
Model	Unit	XE60CA
Operating weight	kg	5960
Standard bucket capacity	m³	0.09-0.23
Main performance
Travel speed	km/h	4.2/2.2
Swing speed	r/min	11
Max. gradeability	/	30°
Ground pressure	kPa	32.5
Max.Bucket digging force	kN	48.3
Max.arm crowd force	kN	32.5
Overall size
Overall length	mm	5960
Overall width	mm	1920
Overall height	mm	2585
Overall width of upperstructure	mm	1780
Track length	mm	2540
Overall width of undercarriage	mm	1920
crawer width	mm	400
Dozer black(width/height)	mm	1920×340
Tumbler distance	mm	1990
Crawer gauge	mm	1550
Clearance under counterweight	mm	710
Ground clearance	mm	385
Min.tail swing radius	mm	1660
Working range
Max. digging height	mm	5630
Max. dumping height	mm	3945
Max. digging depth	mm	3830
Max. vertical wall digging depth	mm	2680
Max. digging reach	mm	6130
Min. swing radius	mm	2460
Max.dozer lifting height	mm	390
Max.dozer cutting depth	mm	560
Angle of arm deflection	Degree	/

We are China High Quality Oriemac Mini Crawler Excavator Xe60ca Xe60d manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
