High Quality Crawler Crane Zcc3200V 24-93m Main Boom Length Big Crane
High Quality Crawler Crane Zcc3200V 24-93m Main Boom Length Big Crane image
Basic Info.
Product Description
|
Items
|
Unit
|
ZCC3200V
|
Remarks
|
|
|
|
Max. lifting capacity ×radius
|
t×m
|
320×6
|
|
|
Main boom
|
Max. lifting moment
|
t×m
|
1935
|
|
|
|
Main boom length
|
m
|
24~93
|
|
|
Light main boom
|
Max. lifting capacity ×radius
|
t×m
|
122×11
|
|
|
Main boom length
|
m
|
67.5~106.5
|
|
|
|
|
Max. lifting capacity ×radius
|
t×m
|
130×9
|
|
|
|
Fixed jib length
|
m
|
9~36
|
|
|
|
Main boom length (with fixed jib)
|
m
|
24~81
|
|
|
|
Max. length of main boom + fixed jib
|
m
|
81+9,63+36
|
|
|
Fixed jib
|
Fixed jib angle
|
°
|
10°,20°, 30°
|
|
|
|
Max. lifting capacity ×radius
|
t×m
|
118×12
|
|
|
|
Luffing jib length
|
m
|
24~66
|
|
|
|
Main boom length (with
|
m
|
24~60
|
|
|
|
luffing jib)
|
|||
|
Luffing jib
|
Max. length of main boom + luffing jib
|
m
|
60+66
|
|
|
|
Main boom angle
|
°
|
85°,75°,65°
|
|
|
|
Speed of hoisting winch 1
|
m/min
|
120
|
The 6th layer
|
|
Winch
|
Speed of hoisting winch 2
|
m/min
|
116
|
The 6th layer
|
|
speed
|
Speed of derricking winch
|
m/min
|
2×50
|
The 6th layer
|
|
|
Slewing speed
|
rpm
|
0~1
|
|
|
|
Traveling speed
|
km/h
|
0~1
|
|
|
|
Rear counterweight
|
t
|
120
|
|
|
|
Central counterweight
|
t
|
40
|
|
|
|
Max. transport weight of a
single component |
t
|
44.5
|
With mast and winch
|
|
|
Total weight with main boom
|
t
|
272
|
With a load hook of 260t
|
|
|
Average ground pressure
|
Mpa
|
0.135
|
|
|
Crane parameters
|
Max. dimensions for transport
(length × width × height) |
m
|
|
|
|
|
13.7×3×3.22
|
|||
|
|
Manufacturer / Model
|
|
WP10G336E344
|
|
|
Engine
|
Rated power / rotational
|
kw/rpm
|
247/1900
|
|
This product not only has the leading lifting performance in the industry, but also has efficient operation, convenient transportation for disassembly and assembly, comfortable control, strong versatility of parts and components, mature and reliable system and complete safety devices. Equipped with the herringbeam from pulling up function, the primary and secondary hook one key switch function, the primary and secondary coil quick release function, engine cold start device, winch monitoring system, lightning protection system, electronic level and other advanced technology, all aspects of performance is better than the domestic and foreign counterparts, is the only choice for your foundation construction!
We are China High Quality Crawler Crane Zcc3200V 24-93m Main Boom Length Big Crane manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
Tags: 130 Ton Hydraulic Crane, Crawler Crane, Zcc3200VSimilar Or Related
