Heli Cpqyd20 2 Ton Mini Forklift Gasoline LPG

Internal Combustion Counterbalanced Forklift Truck

Characteristics

1.01

Manufacturer

HE-LI

1.02

Model

CPQYD20-RCH

1.03

Power type

Gasoline & LPG

1.04

Load Capacity

kg

2500

1.05

Load Center

mm

500

1.06

Driving mode

Sit-on type

 Dimensions

2.01

Max.Lifting height

mm

3000

2.02

Mast height,lowered

mm

2000

2.03

Max.fork lifting height(with backrest)

mm

4030

2.04

Free lifting height

mm

165

2.05

Overhead guard height

mm

2150

2.06

Min.Ground clearance(from bottom of mast)

mm

135

2.07

Overhead guard clearance(from face of seat)

mm

1030

2.08

Traction pin center height

mm

275

2.09

Backrest height

mm

1000

2.10

Overall length(with fork)

mm

3708

2.11

Overall length(without fork)

mm

2580

2.12

Wheelbase

mm

1650

2.13

Front overhang

mm

473

2.14

Rear overhang

mm

457

2.15

Overall Width

mm

1150

2.16

Front tread/Rear tread

mm

970

2.17

Fork Adjustment(Max/Min)

mm

1030/244

2.18

Min.turning radius(external)

mm

2170

2.19

Min.turning radius(internal)

mm

180

2.20

Min.Right angle stacking aisle width

mm

2200

2.21

Mast tilt,front/rear

deg

6/12

Performance

3.01

Max.travelling speed(loaded/unloaded)

Km/h

17/19

3.02

Lifting speed(loaded/unloaded)

Mm/s

520/570

3.03

Lowering speed(loaded/unloaded)

Mm/s

450/500

3.04

Max Draw bar(loaded/unloaded)

kN

15/12.5

3.05

Max.Grade ability(loaded/unloaded)

%

35/25

Weight

4.01

Total weight(oil included)

kg

3420

4.02

Load ability(loaded) front/rear

kg

4770/650

4.03

Load ability(unloaded) front/rear

kg

1680/1820

Tire

5.01

Tire No. X= Drive wheel(front/rear)

2x/2

5.03

Tire size (front)

7.00-12-12

5.04

Tire size (rear)

6.00-9-10

Dive Transmission devices

6.01

Battery(voltage/capactiy)

V/Ah

12/80

6.02

Engine Manufacturer/Model

GCT K21

6.03

Engine Type

GAS/LPG

6.04

Rated power/rotational speed

Kw/rpm

31.2/2200

6.05

Max.torque/rotational speed

Nm/rpm

143.7/1600

6.06

Cylinder Number.

4-89*83
