Heli 3t Electric Forklift with Side Shifter 3-Stage Mast Cpd30 Electric Forklift
Heli 3t Electric Forklift with Side Shifter 3-Stage Mast Cpd30 Electric Forklift image
Basic Info.
Product Description
Product description
Powerful engine and transmission system
Power and transmission system is composed of excellent components by using advanced manufacturing technology and machine and high quality engine.
This combination made the truck powerful reliable
Reliable special designed instrument
Solid State Digital instrument with built-in intellectual chip, what makes it sensitively, accurately, reliably, low power
consumption and long-life. It also works in wide temperature range(-40ºC~+80ºC) and with high interference resistant capability.
Scientific ergonomic application
We use scientific ergonomic method to design H2000 Forklift truck. The operation space has been efficiently enlarged. The rough feeling of the driver has been reduced to the lowest extends.
Strict environment protection design
All the safety concerned key components, such as steering axle with rubber, front axle and mast etc, should pass severed
reliability tests. Thicken insulator on the inner surface and the rubber edging can absorb vibration and reduce noise.
| Model | CPD30 | CPD35 | ||||
| Configuration No. | G1/G2 | G1/G2 | ||||
| Load capacity | kg | 3000 | 3500 | |||
| Load center | mm | 500 | 500 | |||
| Standard mast lifting height | mm | 3000 | 3000 | |||
| Free hoisting height | mm | 145 | 150 | |||
| Overall height (upper frame protection) | mm | 2215 | 2215 | |||
| Full length (without pallet fork) | mm | 2485 | 2550 | |||
| Full width (before/after) | mm | 1225 | 1225 | |||
| Wheelbase | mm | 1680 | 1680 | |||
| The minimum ground clearance (the door) | mm | 135 | 135 | |||
| The minimum turning radius (outer) | mm | 2210 | 2270 | |||
| Least square channel width (1200 * 1200 mm tray, 20 mm gap) |
mm | 4095 | 4160 | |||
| Pallet fork length * width * thickness | mm | 45*125*1070 | 50*125*1070 | |||
| The door frame Angle(before/after) | deg. | 6/10 | 6/10 | |||
| Tire type(before/after) | Pneumatic tyres | Solid tire | ||||
| Maximum speed (full/empty) | km/h | 15.0/15.5 | 14.5/15.0 | |||
| Maximum gradeability (full/empty) | % | 15/22 | 12/17 | |||
| Hoisting speed (full/empty) | mm/s | 280/450 | 250/440 | |||
| Battery capacity | V/Ah | 80/480 | 80/480 | |||
| Control mode (driving, pump) | Ac/dc control | Ac/dc control | ||||
| The total battery (reservation) | kg | 4810 | 5500 | |||
| *Ac lifting speed (full/empty) | mm/s | 340/460 | 325/450 | |||
| *Control mode (driving, pump) | Exchange control | Exchange contro | ||||
We are China Heli 3t Electric Forklift with Side Shifter 3-Stage Mast Cpd30 Electric Forklift manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
Tags: 3t Forklift, Cpd30 Price, Heli ForkliftSimilar Or Related
-
