Heavy Duty 10 Ton Zoomlion Fd100 with 10000kg Loading Capacity and Isuzu Engine in Stock

Heavy Duty 10 Ton Zoomlion Fd100 with 10000kg Loading Capacity and Isuzu Engine in Stock image

Get a Quote Email to us

Product Description

Basic Info.

Model NO.

FD100

Lift height

3000~5000mm

Condition

New

Rated Loading Capacity

10000kg

Max. Lifting Height

3000mm

Fork Length

1220mm

Forkwidth

175mm

Engine

Quanchai Isuzu Xinchai

Transport Package

Nude Package

Specification

5230*2230*2850mm

Trademark

ZOOMLION

Origin

Anhui, China

HS Code

8430691100

Production Capacity

100pieces/Month

Product Description

Heavy duty 10 ton ZOOMLION FD100 with 10000kg loading capacity and ISUZU engine in stock

Features:

Safe & Reliable
• Reinforced mast with wide view design improves efficiency and safety;
• Engine is with large torque and capacity, which is powerful and can meet different operation demands;
• Lifting system is equipped with up and down buffer cylinders, which reduce shock and vibration efficiently;
• Hydraulic system is equipped with the throttling valve, which makes operation safe and reliable;

Comfortable & practical
• Scientific ergonomic design makes operation more portable and comfortable. Seat and backrest are adjustable. Steering wheel tilt angle is also adjustable, which leaves more legroom. Shift operation is quick and simple;
• The forklifts are nice in appearance with streamline design. They work stably with high efficiency and good grade ability and can be operated in bad working conditions;
• Integral overhead guard, disposable stamping ceiling, equipped with five transparent plastic cover, with good lighting and rain protective features.

Parameters:

Specifications	unit	FD100
Characteristics	Power			diesel
	Rated Capacity		kg	10000
	Center of load		mm	600
	Lifting height		mm	3000
	Free lifting height		mm	220
	Forks L×W×H		mm	1220×175×80
	Tilt Forward/Backward		.	6/12
	Min.turning radius		mm	3900
	Min.ground clearance(Mast)		mm	250
	Overhead guard height		mm	2600
	Height from seat to overhead guard		mm	1090
	Front overhang		mm	715
Perf	Max.traveling speed(loaded)		km/h	26
	Max.lifting speed(loaded/empty)		mm/s	290/350
	Drawbar pull/Gradeability		kN/%	57/20
Dimensions	Overall length (without fork)		mm	4260
	Overall width		mm	2230
	Mast lowered height		mm	2850
	Mast extended height		mm	4335
Chassis	Tire	Front		9.00-20-14PR
	Tire	Rear		9.00-20-14PR
	Wheelbase		mm	2800
	Tread width	Front/Rear	mm	1600/1700
	Curb weight	None-load	kg	12500
Powertrain	Battery	Voltage/Capacity	V/Ah	(12/90)x2
	Engine	Model		XC6110
		Rated power	kw/r.p.m	83/2000
		Rated torque	Nm/r.p.m	450/1450
		Cylinder amount		6
		Bore×Stroke	mm	110×125
		Displacement		7.127
	Fuel tank		L	140
	Transmission			1/1 automatic transmission
	Working pressure		MPa	20

Our service:

We are China Heavy Duty 10 Ton Zoomlion Fd100 with 10000kg Loading Capacity and Isuzu Engine in Stock manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
