Haitui Large 320HP Hydraulic Crawler Bulldozer HD32 SD32 SD8n

Haitui Large 320HP Hydraulic Crawler Bulldozer HD32 SD32 SD8n image

Get a Quote Email to us

Product Description

Overview
Product Description
Detailed Photos
Product Parameters
Company Profile

Basic Info.

Model NO.

HD32

Engine Power

147~515kw

Certification

CE, ISO9001: 2000

Condition

New

Color

Orange

Transport Package

Nude Package

Specification

6880*4130*3725 mm

Trademark

SINOMADA

Origin

China

Production Capacity

100 Units/Month

Product Description

HAITUI Large 320HP Hydraulic Crawler Bulldozer HD32 SD32 SD8N
Good quality & Best price

•NTA855-C360S10 engine which can meet national III emission gives you more power and reliability you need. With exhaust turbocharger, it can still work normally at altitude of 4,300 meters.

•The highly reliable power shift transmission, stable torque converter and the two-stage straight-tooth structure final drive transmit power efficiently.

•With independent engine cooling water tank, chassis oil cooler, water and air intercooler provides excellent cooling performance and simple maintenance operation to ensure continuous operation of the machine.

•The main frame of the full box structure adopts steel plate welded full box type integral structure, which is welded with the rear axle box. It has high impact load bearing capacity and resistance to bending and twisting. High quality weld seam ensures the main frame has a full life cycle.

•The final drive is driven low and provides more powerful driving force and efficient gradeability. The crawler-type walking chassis has reached the international advanced level and is suitable for various complicated working conditions, with high reliability and carrying capacity.

•The standard straight tilt blade features powerful cutting force and the three-shank ripper can be equipped for the ripping of clay and frozen earth, featuring high working efficiency and super-strong penetrating force.

Overall	Dimension	6880×4130×3725 mm
	Operating Weight	37200 kg
ENGINE	Model	NTA855-C360S10
	Type	Water-cooled,in-line,Overhead valve direct injection,turbocharged
	Number of Cylinders	6
	Bore × Stroke	Φ139.7×152.4 mm
	Piston Displacement	14.01 L
	Rated Power	257 KW (345HP) @2000 rpm
	Max Torque	1440 N·m @1400 rpm
	Fuel Consumption	245 g/kW·h
TRAVEL SPEED	Gear	1st	2nd	3rd
	Forward	0~3.6 km/h	0~6.6 km/h	0~11.5 km/h
	Reverse	0~4.4 km/h	0~7.8 km/h	0~13.5 km/h
UNDERCARRIAGE SYSTEM	Type	Sprayed beam, suspended structure of equalizer
	Track Shoe type	Single Grouser
	Width of Track shoe	560 mm
	Pitch	228.6 mm
	Track Gauge	2140 mm
	Ground Pressure	0.105 Mpa
HYDRAULIC SYSTEM	Max Pressure	14 Mpa
	Pump Type	Gear Pump
	Displacement	355 L/Min
	Bore of Working Cylinder	140 mm × 2
BLADE	Blade Type	Straight-tilt Blade	Angle Blade	Semi-U-blade
	Blade Capacity	10 m³	6 m³	11.9 m³
	Blade Width	4130 mm	5000 mm	4130 mm
	Blade Height	1590 mm	1140 mm	1710 mm
	Max Drop Below Ground	560 mm	630 mm	560 mm
THREE SHANK RIPPER	Max digging depth	842 mm
	Max lift above ground	883 mm
	Weight of 3-shank ripper	3802 kg
SINGLE SHANK RIPPER	Max digging depth	1250 mm
	Max lift above ground	965 mm
	Weight of 3-shank ripper	3252 kg

We are China Haitui Large 320HP Hydraulic Crawler Bulldozer HD32 SD32 SD8n manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
