Foton Lovol 5 Ton Wheel Loader FL956f
Foton Lovol 5 Ton Wheel Loader FL956f image
Basic Info.
Product Description
Specifications
Excellent productivity
Built for Efficiency
Always Reliable
Features
1. Equipped with the famous WEICHAI engine which is powerful, reliable, low in oil consumption, energy-efficient and environmentally friendly.
2. The plate-fin radiator provides the complete radiator with higher strength and optimized heat dissipation performance. The more excellent heat dissipation effect allows the vehicle to operate normally at 50° C for a longer time.
3. The 360° Panoramic cab provides a larger interior and a more clear vision.
4. Using the three-bump flow-converging system, the steering system is able to operate more easily under idling conditions.
5. The hydraulic pressure hose connection uses the 24° Cone sealing technology. Using the integral forged structure, the high-pressure tube is able to stop any leakage.
6. The main blade plate of the bucket uses the new wear-resistant steel plate, substantially improving wearing properties.
7. The side-opening hood with an oversized opening angle maximizes the inspection and repair space, providing ease of maintenance and servicing.
8. The hydraulic oil tank is rotatable to maintain easy servicing of the oil pump and bivariate speed-change valve.
| Complete machine parameters | |
| Rated load(kg) | 5000 |
|---|---|
| Operating mass (standard)(kg) | 16600 |
| Bucket capacity(m³) | 2.8 |
| Boom lifting time(S) | 5.57 |
| Sum of three items(S) | 10.2 |
| Max. traction force(kN) | ≥160 |
| Max. breakout force(kN) | ≥175 |
| Running system | |
| Forward speed range(km/h) | 42 |
| Backward speed range(km/h) | 17.5 |
| Gearbox shift | Front : 2 gears rear: 1gears |
| Max. gradeability(°) | 30 |
| Steering angle(°) | 37°+-1° |
| Tire model | 23.5-25 |
| Service brake | Single circuit, air-over-oil four-wheel caliper disc brake |
| Parking brake | flexible shaft control caliper disc brake |
| Tire center(mm) | 5665 |
| Outside of bucket(mm) | 6850 |
| Hydraulic system | |
| Working system pressure(Mpa) | 18 |
| Working system displacement(ml/r) | 100 |
| Steering system pressure(Mpa) | 16 |
| Steering system displacement(ml/r) | 80 |
| Hydraulic oil volume(L) | 210 |
| Working scope | |
| Outline dimension(mm) | 7700×2980×3430 |
| Wheelbase(mm) | 2920 |
| Track(mm) | 2250 |
| Min. grounding distance (at hinge position)(mm) | 480 |
| Max. unloading height(mm) | 3135 |
| Unloading distance at max. unloading height(mm) | 1195 |
| Engine parameters | |
| Model | Weichai WD10G220E23 |
| Type | Six-cylinder, in-line, direct injection, turbocharging, and water cooling |
| Rated power(Kw/rpm) | 162/2200 |
| Max. torque / speed(N.m/rpm) | 890// |
| Cylinder bore x stroke(mm) | Φ126Χ130 |
| Displacement(L) | 9.726 |
| Fuel consumption rate at rated working condition(g/Kw.h) | 210.5 |
| Fuel tank capacityt(L) | 280 |
We are China Foton Lovol 5 Ton Wheel Loader FL956f manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
