Factory Supply 6ton Heavy Construction Machine Mini Excavator Xe60da for Digging
Factory Supply 6ton Heavy Construction Machine Mini Excavator Xe60da for Digging image
Basic Info.
Model NO.
XE60DA
Bucket Capacity
0.23m3
Size
Medium-Sized
Certification
CE, ISO9001: 2000
Condition
New
Max. Digging Height
5630 mm
Max. Digging Depth
3830 mm
Max Digging Radius
6130 mm
Engine Model
4tnv94L-Bvxg
Power Output
36.2/2100 Kw/Rpm
Fuel Tank
110 L
Hydraulic Oil Tank
77 L
Arm Digging Force
32.5 Kn
Bucket Digging Force
48.3 Kn
Quantity of Cylinders
4
Travel Speed
4.2/2.2 Km/H
Swing Speed
10 R/Min
Gradeability
35
Ground Pressure
32.5 Kpa
Rated Flow of Main Pump
151.2 L/Min
Transport Package
Container
Specification
6010 kg
Trademark
Top Brand
Origin
China
HS Code
8429521200
Production Capacity
300/Month
Product Description
6t Hydraulic Excavator XE60D XE60DA Mini Excavator with Cheap Price
Contact Way
Product Overview
XE60DA adopts a good engine excellent in environmental protection and energy saving. Moreover, it uses a load sensitive hydraulic system, able to guarantee operator’s better controlling of the machine and better movement coordination, reduce the demand for operation proficiency of the driver; in addition, the reliability of this system has been recognized by the majority of users.
The stress analysis and structure optimization of such key components platforms, swing arms, bucket rods and lower chassis has fully guaranteed the reliability of the structural members.
The daily maintenance is sufficiently convenient and you only need to open the rear hood for maintenance of the engine oil, fuel and air filters.
Product Paramenters
|
Sales model
|
Unit
|
XE60DA
|
|
|
Operating weight
|
Kg
|
6010
|
|
|
Bucket capacity
|
m³
|
0.23
|
|
|
Engine
|
Model
|
/
|
4TNV94L-BVXG
|
|
Direct injection
|
/
|
√
|
|
|
Four strokes
|
/
|
√
|
|
|
Water cooling
|
/
|
√
|
|
|
Turbo-charging
|
/
|
×
|
|
|
No. of cylinders
|
/
|
4
|
|
|
Output power
|
kw/rpm
|
36.2/2100
|
|
|
Maximum torque/speed
|
N.m/rpm
|
207.4/1000
|
|
|
Main performance
|
Travel speed
|
km/h
|
4.2/2.2
|
|
Swing speed
|
r/min
|
10
|
|
|
Gradeability
|
°
|
35
|
|
|
Ground pressure
|
kPa
|
32.5
|
|
|
Bucket digging force
|
kN
|
48.3
|
|
|
Arm digging force
|
kN
|
32.5
|
|
|
Maximum traction
|
kN
|
50.5
|
|
|
Hydraulic system
|
Rated flow of main pump
|
L/min
|
151.2
|
|
Main safety valve pressure
|
MPa
|
24.5
|
|
|
Travel system pressure
|
MPa
|
24.5
|
|
|
Rotary system pressure
|
MPa
|
24
|
|
|
Pilot system pressure
|
MPa
|
3.5
|
|
|
Oil Capacity
|
Fuel tank capacity
|
L
|
110
|
|
Hydraulic tank capacity
|
L
|
77
|
|
|
Engine oil capacity
|
L
|
12
|
|
|
Appearance size
|
Overall length
|
mm
|
5860
|
|
Overall width
|
mm
|
1920
|
|
|
Overall height
|
mm
|
2585
|
|
|
Width of platform
|
mm
|
1780
|
|
|
Track length
|
mm
|
2540
|
|
|
Working scope
|
Max. digging height
|
mm
|
5630
|
|
Max. dumping height
|
mm
|
3945
|
|
|
Max. digging depth
|
mm
|
3830
|
|
|
Max. digging radius
|
mm
|
6130
|
|
|
Standard configuration
|
Length of boom
|
mm
|
3000
|
|
Length of arm
|
mm
|
1600
|
|
|
Bucket capacity
|
m³
|
0.23
|
|
Details Images
