Factory Direct Sale 70 Ton Middle Size Hydraulic Truck Crane Qy70kc with
Factory Direct Sale 70 Ton Middle Size Hydraulic Truck Crane Qy70kc with image
Basic Info.
Model NO.
QY70KC
Type
Straight Arm
Engine Rated Power
360kw
Max. Travel Speed
75km/H
Max. Lifting Load
100t
Total Weight in Travel
54900kg
Base Boom
13.5m
Transport Package
Nude Package
Specification
15600*3000*3850
Trademark
Xuzhou factory
Origin
China
HS Code
8429521200
Production Capacity
200PCS/Year
Product Description
Factory direct sale 70 ton middle size hydraulic Truck Crane QY70KC with
Description:
> The innovative jib system adopts embedded block, plug-in boom head and international advanced U section jib, which has excellent lifting performance and safe and reliable lifting work.
>The unique stretch and retract technique avoids the bend of the core pipe and cylinder and the break of the boom caused by misoperation, improving the safety of the operations.
>Eight patent techniques ensure the smooth, high efficiency and energy conservation of the lifting, rotation, and luffing systems.
> Adopt the new hydraulic motor with big torque starting point, making the secondary lifting safer.
>The torque limiter adopts colorful LCD display, realizing the intelligence of the failure diagnosis. The precision is ahead of the industry.
>The humanity design makes the cab and control cab more spacious, and easy to operate.
>Six unique manufacturing technologies ensure the high quality.
>The unique stretch and retract technique avoids the bend of the core pipe and cylinder and the break of the boom caused by misoperation, improving the safety of the operations.
>Eight patent techniques ensure the smooth, high efficiency and energy conservation of the lifting, rotation, and luffing systems.
> Adopt the new hydraulic motor with big torque starting point, making the secondary lifting safer.
>The torque limiter adopts colorful LCD display, realizing the intelligence of the failure diagnosis. The precision is ahead of the industry.
>The humanity design makes the cab and control cab more spacious, and easy to operate.
>Six unique manufacturing technologies ensure the high quality.
Parameter:
| Category | Item | Unit | Parameter | |||
| Dimensions | Dimensions (length×width×height) | mm | 13900×2800×3675 | |||
| Wheel base | mm | 1470+4300+1350 | ||||
| Track(Front/ Rear ) | mm | 2314/2314/2063/2063 | ||||
| Front/ Rear overhang | mm | 2380/2150 | ||||
| Weight | Front/ Rear extension | mm | 2250/0 | |||
| Total vehicle mass in travel configuration | kg | 42700 | ||||
| Axle load | 1st axle | kg | 8585 | |||
| 2nd axle | kg | 8585 | ||||
| 3rd axle | kg | 12765 | ||||
| 4th axle | kg | 12765 | ||||
| Power | Engine model | – | D10.38-50 | |||
| Engine rated power/rpm | kW/(r/min) | 276/2000 | ||||
| Max. net power/rpm | kW/(r/min) | 274/2000 | ||||
| Max. output torque/rpm | N.m/(r/min) | 1560/1200-1500 | ||||
| Travel | Max. travel speed | km/h | ≥90 | |||
| Min. stable travel speed | km/h | 2.5~3 | ||||
| Min. turning diameter | m | ≤24 | ||||
| Min. turning diameter at boom tip | m | ≤29 | ||||
| Min. ground clearance | mm | 303.5 | ||||
| Approach angle | ° | 19 | ||||
| Departure angle | ° | 14 | ||||
| Braking distance (at 30 km/h ) | m | ≤10 | ||||
| Max. grade ability | % | ≥45 | ||||
| Fuel consumption per 100 km | L | 40 | ||||
| Noise | Exterior noise level | dB(A) | ≤88 | |||
| Noise level at seated position | dB(A) | ≤90 | ||||
| Main performance | Max. total rated lifting capacity | t | 55 | |||
| Min. rated working radius | m | 3 | ||||
| Turning radius at turntable tail | Counterweight | mm | 3625 | |||
| Auxiliary winch | mm | 3780 | ||||
| Max. load moment | Base boom | kN.m | 2033 | |||
| Fully-extended boom | kN.m | 1225 | ||||
| Fully-extended boom + Jib | kN.m | 624 | ||||
| Outrigger span | Longitudinal | m | 6.1 | |||
| Lateral | m | 7.1 | ||||
| Hoist height | Base boom | m | 11.9 | |||
| Fully-extended boom | m | 44.5 | ||||
| Fully-extended boom + Jib | m | 60.3 | ||||
| Boom length | Base boom | m | 11.6 | |||
| Fully-extended boom | m | 44.5 | ||||
| Fully-extended boom + Jib | m | 60.5 | ||||
| Jib offset angle | ° | 0, 15, 30 | ||||
| Working speed | Boom raising time | s | ≤50 | |||
| Boom fully extended time | s | ≤100 | ||||
| Max. slewing speed | r/min | ≥1.6 | ||||
Our service:
We are China Factory Direct Sale 70 Ton Middle Size Hydraulic Truck Crane Qy70kc with manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
Tags: 70 Ton Truck Crane, Qy70K Truck Crane, Zoomlion Truck CraneSimilar Or Related
