Basic Info.

Model NO.
LW300KN

Type
Medium-sized Loader

Bucket Capacity
2.5m3

Rated Power
92kw

Load Capacity
3t

Machine Weight
10900kg

Transport Package
Nude Package

Specification
7245*2482*3320

Trademark
Oriemac

Origin
China

HS Code
8429510000

Production Capacity
100units Per Month

Product Description

China Best Quality 3Ton LW300KN Small Wheel Loader for Sale


LW300KN Inheritance of classic and high maturity and stability

Product Overview

As an outstanding representative of the industry’s super-heavy-duty models, LW300KN boasts remarkable advantages in terms of "High energy-conservation, efficiency, reliability, and comfort" compared with industry’s like products and is extensively applicable for earthmoving projects, aggregate yards, municipal constructions, and other bulk material transports.



XG’s exclusive technologic advantages

XG’s exclusive energy-conservation technology – The perfect combination between XG’s patented energy-conservation drive system and low speed energy-conservation engine builds the one and only 3t energy-conservation product in the industry, with the economy superior by >10% to the industry’s like products.

XG’s patented lubrication technology – The transmission is applied with the XG’s patented optimal lubrication system design technology to thoroughly improve the industry’s difficulties of insufficient and non-uniform transmission lubrications and make the transmission life remarkably leading the industry.

XG’s patented high strength frame – With the application of the XG’s exclusive high strength single plate beam skeleton structure, the "load-carrying material ratio" is remark ably leading the industry products.

XG’s unique structure design – The extended wheelbase and the classic 3rd generation loader structure realize higher working capacity, smaller turning radius,

and lower wear of rear wheels.

Item Specification Unit
Rated operating load 3000 kg
Bucket capacity 1.5~2.5
Machine weight 10900±200 kg
Dump clearance at maximum lift 2770~3260 mm
Reach at maximum lift 1010~1210 mm
Wheel base 2900 mm
Tread 1850 mm
Height of hinge at maximum lift height 3830 mm
Working height(fully lifted) 4870 mm
Max.breakout force 130 kN
Max.horse power 95 kN
Hydraulic cycle time-raise 5.4 s
Total hydraulic cycle time 9.3 s
Min. turning radius over tyres 5170 mm
Articulation angle 38±1 °
Gradeability 28 °
Tyre size 17.5-25-12PR
Overall machine dimension L×W×H 7245×2482×3320
Model WP6G125E201
Emission standards Emission 2
Rated Power/Speed 92/2200 kW/rpm
Fuel Tank 170 L
Hydraulic Tank 175 L
Travel speed I-gear(F/R) 12/16 km/h
II-gear(F/R) 38/- km/h
Structure and specification are subject to change without notice.In case there is any difference between the description of the machine and the substantial machine,the substantial machine should govern.I
