Brand New 9ton Mining Hydraulic Construction Machine Wheel Loader Clg890h

Product Description
Reinforced rock bucket with thickened plate is made especially for loading aggregates in mines.
Heavy-duty wet type brake axle and braking system ensure the reliability and durability of the product even under
tough work conditions.
ROPS/FOPS certified cab for operator safety and reliable operation in tough conditions.
Fully-sealing and micro-pressuring system ensures the cab is clean and quiet. Silicone oil shock absorber reduces vibration and improves ride comfort.

Product Parameters

Operating weight 30,600 kg

Standard bucket 5.4 m³

Maximum gross power 287 kW (390 hp) @ 1800 rpm

Maximum net power 273 kW (371 hp) @ 1800 rpm

Rated load 9000 kg

Total cycle time 11 s

Tipping load-full turn 20600 kg

Bucket breakout force 245 kN

Dump clearance, full height discharge 3330 mm

Dump reach, full height discharge 1479 mm

Model Cummins QSM11

Emissions EPA Tier 2 / Tier 3 /EU Stage II / EU Stage IIIA

Cooling system Charge air cooling

Length with bucket down 9352 mm

Width over tires 3170 mm

Cab height 3765 mm

Turning radius, outside of tire 7011 mm

Bucket capacity 4.5-9.0 m³

General Purpose 5.4 m³

Light material 7.2, 8.0, 9.0 m³

Heavy-rock 4.5 m³
