Best 180 Degree Rotation 2ton Wall Mounted Jib Crane Price
Best 180 Degree Rotation 2ton Wall Mounted Jib Crane Price image
Basic Info.
Product Description
Product Introduction
Wall-Traveling Jib Cranes provide long lateral movement of materials without taking up floor space or interfering with large overhead cranes. Wall-traveling jibs increase overall plant productivity by quickly handling smaller lifts.
You can cover an entire series of workstations using one agile wall-traveling crane for (conceivably) the entire length of your building.
Wall-Traveling Jib Cranes are cost-effective, custom engineered solutions that are specifically designed to meet your production needs and building specifications
WALL-TRAVELING JIB CRANE FEATURES
• Jib boom is fabricated from standard steel beam.
• End trucks are constructed from channel beam frames and resist twisting.
• Top-running end carriers include double-flanged crane wheels made from forged steel for long service life.
• Crane drive has a squirrel cage motor with double-reduction spur gear reducer.
• Hoist can be chain hoist or wire rope hoist.
• A variety of voltage options; 230-3-60, 380-3-50
| Capacity/Lifting Weight | T | 0.25 | 0.5 | 1 | 2 | 3 | 5 | |
| Type | BXD0.25 | BXD0.5 | BXD1 | BXD2 | BXD3 | BXD5 | ||
| Turning Radius | Degree | 360 | 360 | 360 | 360 | 360 | 360 | |
| Rotate Mode | Electricity | |||||||
| Lifting Speed | m/min | Standard | 4/10/8 | 5/10/8 | 5/8 | 4/8 | 8 | 8 |
| Special | 1/2.5/0.8 | 1.25/2.5 | 1.25/2/0.8 | 1/0.8 | 0.8 | 0.8 | ||
| Maximum Swing Radius | mm | 3000 | 3000 | 3000 | 3000 | 4000 | 4000 | |
| Minimum Swing Radius | mm | 1100 | 1250 | 1300 | 1300 | 1200 | 1100 | |
| Lifting Height | mm | 3000 | 3000 | 3000 | 3000 | 4000 | 4000 | |
| Travelling Speed | m/min | 14/20 | 14/21 | 14/22 | 14/23 | 20 | 20 | |
| Height | mm | 3650 | 3900 | 4100 | 4230 | 5500 | 5750 | |
| width | mm | 3340 | 3363 | 3400 | 3415 | 4450 | 4600 | |
| Self-weight | KG | 950 | 1100 | 1800 | 2100 | 3500 | 4500 | |
| Rotating Speed | R/min | 0.7 | 0.7 | 0.7 | 0.7 | 0.6 | 0.6 | |
Environmental Conditions of Electric Slewing Jib Crane:
1. Power supply of Electric slewing jib crane:
380V-50HZ-3 phase or as your request;
2. The altitude of Electric slewing jib crane installation
location is not exceeding 2000m;
3. Electric slewing jib crane working grade: A3;
4. No flammable, explosive and the strong caustic gas;
5. Electric slewing jib crane is prohibited to lift molten
metal, toxic substances and flammable items.
We are China Best 180 Degree Rotation 2ton Wall Mounted Jib Crane Price manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
