6X4 Sinotruck HOWO 16cubic Meters Concrete Mixer Truck Price

6X4 Sinotruck HOWO 16cubic Meters Concrete Mixer Truck Price image

Get a Quote Email to us

Product Description

Overview
Product Description
Product Parameters
Detailed Photos
Company Profile

Basic Info.

Model NO.

ZZ1317N3667A

Tank Volume

＜5000L

Drive Wheel

6×4

Seats

≤5

Horsepower

351-450hp

Engine Capacity

4-6L

Storage

Concrete

Tire Certification

ECE, GCC, ISO

Tire Design

Bias

Condition

New

Transmission

Hw19710

Rear Axles

Hc16 Ratio:5.73

Front Axles

Hf9 Drum-Type

Front/Rear Overhang(mm)

1500/1739

Wheel Base(mm)

3625+1350

Tires

12.00r20 10pics with One Spare Tire

Approach/Departure Angle(°)

19/26

Maximum Speed(Km/H)

Dimensions(mm)

8214X2496X3386

Capacity

14m3

Transport Package

Roro

Specification

8214x2496x3386mm

Trademark

Top Brand

Origin

China

HS Code

8429510000

Production Capacity

1000units/Moth

Product Description

Sinotruk Howo Diesel Concrete Mixer Drum ZZ1317M3261W Concrete Mixer Truck

Concrete mixer truck consists of truck chassis and concrete mixing delivery device, mixing tank keeping rolling during the transportation process. It is special purpose vehicle that combines the functions of concrete mixing and delivery.
Cement mixer truck has three type: wet material type, material type and semidry material type according to concrete water content in the mixer truck shipment to points. It can be shipped by mixing plant (station) production of concrete or mixed according to the ratio of aggregate (sand and gravel), cement and water. During transport and segregation, it keeps slowly stirring wet material constantly to prevent the initial setting of concrete.

SPECIFICATION			DESCRIPTION
Truck Model			ZZ1317N3667A
Type of Vehicle			16m3 Concrete Mixer Truck
Truck Brand			SINOTRUK-HOWO
Driving Position			Left hand Driving
The Total Mass			31,000kg
Dead Weight			17000
Max speed(km/h)(km/h)			78
Color			Optional
Chassis & Add Components
Frame Details			parallel ladder with U-profiles and riveted cross members
Dimension(Lx W xH)(unloaded)(mm)			12000x2496x3990
Approaching angle/Departure angle(°)			16/12
Overhang(front/rear) (mm)			1500/3000
Wheel base (mm)		1800+3600+1350
Engine
Model		WD615.47
Brand		SINOTRUK
Power		371HP
Emission		EURO II
Displacement(L)		9.726
Type		water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection
Kind of Fuel		Diesel
Clutch & Gear Box System
Clutch		SINOTRUKΦ430mm diaphragm spring clutch
Gear Box		HW19710 10 forwards and 2 reverse.
Brand		SINOTRUK
Axles
Front Axle Model		HF9 axle. Capacity: 9000kg
Rear Axle		HC16 axle. Capacity:2X 13000kg
Electrical System
Battery		2X12V/165Ah
Alternator		28V-1500w
Starter		7.5Kw/24V
Brake System
Service brake		Dual circuit compressed air brake
Parking brake		spring energy, compressed air operating on rear wheels
Auxiliary brake		Engine exhaust brake
Steering system
Model		8118 Germany Brand
Wheels & Tyres
Type		12.00R20 10+1 spare Tubeless tire
Cabin HW76 standard cabin , (single sleeper, with air-condition)
Mixer Body
Agitating Capacity	16m3

We are China 6X4 Sinotruck HOWO 16cubic Meters Concrete Mixer Truck Price manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
