5 Tons Telescopic Boom Truck Mounted Crane Sq5sk2q
5 Tons Telescopic Boom Truck Mounted Crane Sq5sk2q image
Basic Info.
Product Description
1.Single cylinder synchronization guy cable technology makes work efficiency higher than before.
2.Advanced development means make sure that the design is very reliable.
3.The more symmetrical center design of pentagon or hexagon boom make it has bigger anti-bending capacity.
4.Compact hinge point design takes up smaller space.
5.The work is more safety after fitted with alarm device.
6. The integer lifting winch improved the work efficiency greatly and prolonged work life of hydraulic system.
7. Float three -point bridge structure design can lower the accessional stress on the chassis when traveling. 8. Anti-slewing impulse equipment makes vehicle running safety.
|
Model |
SQ5SK2Q |
Unit |
|---|---|---|
|
Max Lifting Capacity |
5000 |
kg |
|
Max Lifting Moment |
12.5 |
T.M |
|
Recommend Powe |
18 |
kw |
|
Max Oil Flow of Hydraulic System |
32 |
L/min |
|
Max Pressure of Hydraulic System |
18 |
MPa |
|
Oil Tank Capacit |
100 |
L |
|
Rotation Angle |
All Rotation |
|
|
Crane Weight |
2074/2170 |
kg |
|
Installation Space |
1000 |
mm |
|
Choice of Chassis |
CA1140PK2L3EA80; DFL1140B; EQ1126KJ1; HFC1132KR1K3; LZ1120LAPT; EQ1141NBJ2; EQ5201GFJ6; EQ5201GFJ6; NXG1160D3ZAL1X |
|
We are China 5 Tons Telescopic Boom Truck Mounted Crane Sq5sk2q manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
