4 Wheel Drive New Mini Backhoe Loader 630A
4 Wheel Drive New Mini Backhoe Loader 630A image
Basic Info.
Product Description
-
1)To adopt the gearbox, torque converter to provide a supper power, walking steadily and higher reliability
2)To combined Excavator and loader as one machine, fully equipped with all function of mini excavator and loader, more suitable for operating in a narrow space, convenient and flexible, reducing the whole purchase coat and running cost.
3)Excavation and loading function are all control, light and flexible, high efficiency.
4)Humanized designed 360 degree swivel seat, all stalinite cab, more broad vision and comfortable driving.
5)Excavation slideslip device make the excavation operations broader and more efficient.
6)For municipal, building, water conservancy, road, water, electricity, garden and other departments, engaged in agricultural construction, pipe laying, cable laying,landscaping and other jobs.
|
Overall Dimension
|
|||
|
1
|
Length(with bucket on ground)
|
7085(mm)
|
|
|
2
|
Width
|
2313(mm)
|
|
|
3
|
Load Bucket width
|
2313(mm)
|
|
|
4
|
Height(To the top of the cab)
|
2710 (mm)
|
|
|
5
|
Height(To the top of the digging pole)
|
3424 (mm)
|
|
|
6
|
Wheelbase
|
2155.5(mm)
|
|
|
7
|
Back wheel Tread
|
1700(mm)
|
|
|
8
|
Fore wheel Tread
|
1880(mm)
|
|
|
9
|
Min. ground clearance
|
355(mm) for 2WD 275(mm) for 4WD
|
|
|
Main Loading Technical Specification
|
|||
|
1
|
Rated load
|
1700(Kg)
|
|
|
2
|
Operating weight
|
7600KG
|
|
|
3
|
Max lifting capability
|
>2500KG
|
|
|
4
|
Rated load bucket capacity
|
1.0(m3)
|
|
|
5
|
Max. load breakout force
|
>60kN
|
|
|
6
|
Max. dump clearance
|
2714(mm)
|
|
|
7
|
Max. Dump reach
|
845(mm)
|
|
|
8
|
Dump angle at any position
|
≥43.5°
|
|
|
9
|
Min. turning radius
|
||
|
|
(1) Outside of bucket
|
5280(mm) for 2WD 5670(mm) for 4WD
|
|
|
(2) Center of front wheel
|
3795 (mm) for 2WD 4380(mm) for 4WD
|
||
|
10
|
Lifting time of loading bucket
|
≤4.5(sec.)
|
|
|
11
|
Lowering time of loading bucket
|
≤7.5(sec.)
|
|
|
12
|
Dumping time
|
≤1.5(sec.)
|
|
|
13
|
Traveling speed(Km/h),4 forward and 4 reverse
|
||
|
|
(1) 1 gear forward
|
6
|
|
|
(2) 2 gear forward
|
9.6
|
||
|
(3) 3gear forward
|
20.5
|
||
|
(4) 4 gear forward
|
38
|
||
|
(1) 1 gear reverse
|
6
|
||
|
|
(2) 2 gear reverse
|
9.6
|
|
|
(3) 3gear reverse
|
20.5
|
||
|
(4) 4 gear reverse
|
38
|
||
|
Main Digging Technical Specification
|
|||
|
1
|
Rated digging bucket capacity
|
0.3(m3)
|
|
|
2
|
Max. digging depth
|
4405(mm)
|
|
|
3
|
Max. digging force
|
>50±10%kN
|
|
|
4
|
Max. digging radius
|
5481(mm)
|
|
|
5
|
Max. dumping height
|
3737(mm)
|
|
|
Diesel engine
|
|||
|
1
|
Model
|
WD WP4G95E221
|
|
|
2
|
Type
|
Direct injection. Turbocharged. Water cooling
|
|
|
3
|
Rated output
|
70 (kW)
|
|
|
4
|
Total exhaust of cylinder
|
4.5(L)
|
|
|
5
|
Inter-bore of cylinder/stroke
|
102/130(mm)
|
|
|
6
|
Voltage of starting motor
|
12(V)
|
|
|
7
|
Rated speed
|
2200(r/min)
|
|
|
8
|
Max. Torque
|
380(N.M)
|
|
|
9
|
Starting type
|
Electric
|
|
|
10
|
Min. specific fuel consumption
|
216(g/Kw.h)
|
|
|
Working Device Hydraulic System
|
|||
|
1
|
Model of oil pump
|
JHP2063C
|
|
|
2
|
System pressure
|
210(kgf/cm2)
|
|
|
3
|
Model of load valve
|
ZL20.3S4C-00
|
|
|
4
|
Model of excavate valve
|
WJ20.7SC3-00
|
|
|
Steering System
|
|||
|
1
|
Type
|
Fore wheel Steering
|
|
|
2
|
Model of steering pump
|
JHP2063C
|
|
|
3
|
Model of Redirector
|
BZZ5-E160B+ FKB-3022
|
|
|
4
|
System pressure
|
140(kgf/cm2)
|
|
|
Oil Capacity
|
|||
|
1
|
Fuel(diesel)
|
151(L)
|
|
|
2
|
Engine lubricating oil
|
11(L)
|
|
|
3
|
Oil for converter and gear box
|
For 2WD
|
18.5(L)
|
|
For 4WD
|
21(L)
|
||
|
4
|
Oil for hydraulic system
|
110(L)
|
|
|
5
|
Oil for driving axles(F/R)
|
7.6+17(L)
|
|
Product Configuration
