26ton Shantui Heavy Duty Pneumatic Tire Road Roller Sr26t

26ton Shantui Heavy Duty Pneumatic Tire Road Roller Sr26t image

Get a Quote Email to us

Product Description

Basic Info.

Model NO.

SR26T

Travel Speed

40cm/s

Centrifugal Force

14KN

Certification

CE, ISO 9001:2000, ISO 9001:2008

Condition

New

Operating Weight

26000(Kg)

Ground Pressure

200-420(Kpa)

Gradeability

20(%)

Engine Model

Sc7h

Rated Power/Rated Speed

118/1800(Kw/Rpm)

Forward Speed

F1:0-8,F2:0-18(Km/H)

Reversing Speed

R1:0-8,R2:0-18(Km/H)

Wheelbase

3840(mm)

Fuel Tank

180(L)

Compacting Width

2750(mm)

Transport Package

Nube, Roro, Container

Specification

5060*2892*3338mm

Trademark

Shantui

Origin

Shandong, China

HS Code

8429401100

Production Capacity

500

Product Description

26ton Shantui Heavy Duty Pneumatic Tire Road Roller SR26T

Product description

Operating cost

The proprietary match technology can achieve high operating efficiency and reasonable fuel economy.

The configuration of brand core parts achieves high quality and reliability and reduces the malfunction downtime.

Working performance

The high-strength three-point swing M frame for front wheels guarantees the uniform compacting on rugged ground.

The special tires for construction machinery feature good wear resistance and long life.

The hydraulic torque converter and power shift transmission with automatic stepless speed regulation are applied to achieve automatic adaptability and stable compacting drive of the road roller.

High maintenance convenience

The centralized oil drainage system eases the maintenances of engine, transmission, radiator, fuel tank, and hydraulic oil tank.

All body parts are designed with service hatches and uplifting covers to ease the maintenances and repairs of parts.

The centralized lubrication system for the rear wheels eases the centralized maintenances of the rear wheels.

High operating comfort

The downward exhaust design and the optimized heat dissipation air ducts reduce the radiation of engine compartment temperature towards the cab.

The double control mode is designed strictly as per ergonomic principles and the functional buttons are centralized to ease the access.

The octahedral cab provides a broad vision.

Specification

Parameter name	SR26T
Performance parameters
Operating weight (Kg)	26000
Exciting force (KN)	–
Vibration frequency (Hz)	–
Nominal amplitude (mm)	–
Ground pressure (KPa)	200-420
Gradeability (%)	20
Engine
Engine model	SC7H
Rated power/rated speed (kW/rpm)	118/1800
Overall dimensions
Overall dimensions of machine (mm)	506028923338
Driving performance
Forward speed (km/h)	F1:0-8,F2:0-18
Reversing speed (km/h)	R1:0-8,R2:0-18
Chassis System
Wheelbase (mm)	3840
Tank capacity
Fuel tank (L)	180
Working device
Compacting width(mm)	2750

Product photos

Company Information

We are China 26ton Shantui Heavy Duty Pneumatic Tire Road Roller Sr26t manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
