14ton a Radio Control Tracked Shantui Bulldozers Farm Escarificador Dh13-K2
14ton a Radio Control Tracked Shantui Bulldozers Farm Escarificador Dh13-K2 image
Basic Info.
Product Description
CHARACTERISTIC
-
Power System
The installed N67 electronic control engine conforms to the EPA Tier4final/EU Stage IV emission regulation, featuring stronger power and higher energy-saving and environmental-friendliness. The after-treatment system adopts FPT’s unique HI-eSCR technology, requiring no external EGR. The 600h oil maintenance interval reduces the maintenance costs.
The Shantui’s innovative hydrostatic drive optimization technology is applied to achieve higher efficiency and energy-saving. The multiple operating modes are at the user’s choice depending on the load of actual working condition to realize the reasonable match among power, efficiency, and energy consumption.
Standard mode – It can provide strong power performance and excellent operating control performance for the operator.
Power mode – It can provide stronger power performance to meet your higher needs for heavy-load condition.
Economic mode – Under medium-load/light-load condition, it can run the engine at relatively low speed to thus remarkably reduce the fuel consumption. Meanwhile, in event of power need, it can quickly increase the speed to save the fuel by 5%~20%. The specific condition depends on the application condition.
The air suction type temperature controlled fan incorporates the reverse self-cleaning function, featuring high efficiency and energy-saving.
- The hydraulic torque converter with locking function is applied to output the torque along with the variation of load, featuring powerful load adaptability (Hydraulic drive at low speed and mechanical drive at high speed) and high fuel economy (Fuel-saving by 10%~15%).
- The normally closed brake plays the parking brake function to effectively prevent the machine gliding on slopes and realize high safety.
- Not relying on the main frame, the final drive adopts modular design and can be assembled independently to ease the repairs.
- The high pressure hydraulic system in system pressure of 21MPa is applied to effectively reduce the volumes of hydraulic parts and achieve good operating inching performance.
- The working device is operated by single pilot joystick, featuring flexible operations, high handiness and comfort, and high reliability;
- The traveling system is controlled by single electronic control joystick to realize the "AMT fingertip gearshift" function.
- The high-strength heptahedral cab is applied to achieve large space, broad vision, and good space airtightness and effectively isolate the external noise.
- The high-power A/C and heating system is installed and the air vents are reasonably arranged to achieve excellent cooling and heating performances.
- The standard high-grade luxury upholstery integrates A/C air ducts, control panel, cup holder, cigarette lighter, and radio.
- The standard 18.9m³ semi-U blade features high blade capacity and high working efficiency. The high-strength box structure and high-performance wear-resistant materials are applied to handle all severe working conditions with ease.
- The huge single-shank ripper incorporates super-strong penetrating force and can be for the stripping of rock stratum.
- The chassis system adopts track rollers of type K suspension design to realize the floating traveling function, achieve excellent driving/riding comfort, reduce the rigid impact onto the machine, prolong the machine life, increase the ground area under complicated working conditions, and ensure strong road adaptability and good traction performance.
- The installed temperature controlled fan system can intelligently control the fan speed and adjust on-demand to improve the fuel economy and realize better energy-saving.
- The high-strength and highly wear-resistant drive sprocket, idler, track roller, carrier roller, and track and the wearing parts (Including cutting edges, end bits, and tooth tips) manufactured independently by Shantui guarantee higher durability.
Product Parameter
| Parameter name | DH13-K2 XL (Extended version) | DH13-K2 LGP(Super-wetland version) |
| Performance parameters | ||
| Operating weight (Kg) | 14200kg/31306lb (With traction frame) | 14800kg/32628lb (With traction frame) |
| Ground pressure (kPa) | 48 | 36.9 |
| Engine | ||
| Engine model | N67 | N67 |
| Rated power/rated speed (kW/rpm) | 118/2200 | 118/2200 |
| Overall dimensions | ||
| Overall dimensions of machine (mm) | 5010*3380*3110 | 5010*3680*3110 |
| Driving performance | ||
| Forward speed (km/h) | 0~10km/h(6.2mph) | 0~10km/h(6.2mph) |
| Reversing speed (km/h) | 0~10km/h(6.2mph) | 0~10km/h(6.2mph) |
| Chassis System | ||
| Center distance of track (mm) | 1930 | 2150 |
| Width of track shoes (mm) | 560 | 760 |
| Ground length(mm) | 2640 | 2640 |
| Tank capacity | ||
| Fuel tank (L) | 263 | 263 |
| Working device | ||
| Blade type | Angle Blade | Angle Blade |
| Digging depth (mm) | 460 | 460 |
| Ripper type | Three-tooth ripper | Three-tooth ripper |
| Ripping depth (mm) | 500 | 500 |
